B2440M無刷直流電機
- 所屬分類：[全部恒驅直流無刷電機]
- 產品簡介：特征：雙轉向，信號功能，鎖定保護，無級調速，低噪音，低電磁干擾，超長壽命3000-15000小時
- 訂購熱線：400-0755-631
- 下載資料：資料下載
|
|
B2440M |
Output Power 輸出功率: 1W~20W |
Weight 重量: 82g (Approx.) |
|
Brushless DC Motor-Typical Application（In development） 直流無刷電機-典型應用（研發中） Automotive Parts: Pump 汽車部件：微型泵 Home Application: White Goods, Small Appliance, Fanner, Electric Curtain 家用電器：白色家電，小家電，電風扇，電動窗簾 Medical Apparatus: Medical Pump, Blood Pressure Meter, Surgery Tools, Medical Stirrer, 醫療器械：醫療泵，血壓計，手術器械，攪拌機，離心機 Industry Equipment: Electric Valve, Portable Screwdriver, Air Pump, Water Pump, Vacuum Pump 工業設備：電動閥門，手持電批，氣泵，水泵，真空泵 Business Equipment: Printer, Copier, Projector, Scanner, Cash Register 商業設備：掃描儀，點鈔機 Personal Care: Hair Dryer, Electric Shaver, Massager 個人護理：風筒，電動須刨，按摩器 |
|||
|
Model 型號 |
Voltage(V) 電壓 |
No Load 空載 |
Rated Load 額定負載 |
Stall 堵轉 |
||||||
|
Operating Range |
Rated |
Speed (rpm) |
Current (A) |
Torque (mNm) |
Speed (rpm) |
Current (A) |
Output P. (W) |
Torque (mNm) |
Current (A) |
|
|
B2440M-S01 |
4~8 |
5 |
1400 |
0.24 |
17.5 |
927 |
0.72 |
1.70 |
49.5 |
1.5 |
|
B2440M-S02 |
8-26 |
12 |
2652 |
0.17 |
30 |
1781 |
0.83 |
5.60 |
91.3 |
2.5 |
|
B2440M-S03 |
8-26 |
24 |
4380 |
0.14 |
50 |
2923 |
1.02 |
15.3 |
150 |
3.0 |
Characteristic: CW & CCW, Signal function available, Locked rotor protection, Stepless speed regulation, Low noise, Low EMI, Long life 3000-15000hrs 特征：雙轉向，信號功能，鎖定保護，無級調速，低噪音，低電磁干擾，超長壽命3000-15000小時
|
Notice: Data in this typical specification sheet are for other certain customer. Voltage, rated torque, speed, current, power and shaft extension feature & dimension can be changed to meet customer specific requirement. 注意：上述規格僅針對特定客戶，電壓、扭矩、轉速、電流、功率、輸出軸的特征和尺寸等都可以按照客戶的特殊要求進行調整。 |
Outline Drawing 外形圖:
|
Usable machine screw length 2.0mm max. from motor mounting surface |
Unit: Millimeter |
Performance Curve 性能曲線:
|
B2440M-S03 24V |
